This is (hopefully) a more user-friendly CIC/NBT FSC Key Generator for Windows, Linux and OSX based off of the work of the original FSC Key Generator and Intel123's certificate Patcher. The Key Generator will auto-detect and accept either Base64 (Text) or binary FSC file inputs, as well as the file type (1B or NBT).

Here is an instruction on how to extract your DE (NBT) or 1B (CIC) file, generate the FSC code for BMW F series.
> 3 steps to generate BMW CIC& NBT FSC Code

Prequisites:

PSDZData Lite (lite version is fine for FDL coding, you only need the full package if you want to flash ECUs)

Token (not required to reach FSC Extended)

To get the E-sys and psdzdata files, go to

CIC PREMIUM 2014 Maps:

http://www.e90post.com/forums/showthread.php?t=893113

NBT NEXT 2015 & 2016 Maps:

http://www.e90post.com/forums/showthread.php?t=995629

How to start upESys:

if you are generating maps for NEXT then you need to follow the guide for DE

if you are generating maps for MOVE, MOTION or PREMIUM then you need to follow the guide for 1B

Extracting the DE or 1B file:

Fire up Esys

make sure your connected to the F20 (not F20_Direct) via your VIN and then in

the left hand vertical menu select FSC Extended.

For NBT (DE File):

In the Parameter section enter:

  1. Diagnostic Address (hex) = 0x63
  2. Click on the Identify button and the Base variant HU_NBTwill be populated
  3. Application ID for NBT= 0xDE
  4. Upgrade Index = 0x1

For CIC (1B File):

In the Parameter section enter:

  1. Diagnostic Address (hex) = 0x63
  2. Click on the Identify button and the Base variant HU_CICwill be populated
  3. Application ID for NBT= 0x1B
  4. Upgrade Index = 0x1

In the Action section:

  1. Select Store FSC and move from left to the right
  2. Click on the Read button
  3. Click Save and and name the file in the following formatXXXXXXX.fsc where XXXXXXX is last seven letters/numbers of your VIN or your donor NBT vin if you have retrofitted the NBT.
  4. [Optional] You can now disconnect eSys from your car as the next stages can be performed offline.

Bmw Fsc Code Generator Cic Nbt Code

Getting the Code Generation Software:

Unzip the directory attached. The directory can be placed/run from anywhere.

Generating the FSC code using the BMW_CIC_NBT_FSC_Generator for NBT:

If you are generating NBT, copy fsc.exe in the NBT_FSC directory to the tools directory

  1. Place your XXXXXXX.fsc into your tools directory (same location as the Base64.exe)
  2. Open a command prompt (DOS Screen) and go to the tools directory
  3. Type “Base64 XXXXXXX.FSC XXXXXXX_000DE001.FSC” and press enter
  4. Open BMWFSCNBTGenerator.

exe

  1. Click “Browse” and select the XXXXXXX_000DE001.FSC file you generated in step 3, it

should be in your tools directory.

  1. Choose your map product from the list (For me it was “Road Map EUROPE NEXT 20151)
  2. Click “Generate”

Generating the FSC code using the BMW_CIC_NBT_FSC_Generator for CIC:

If you are generating CIC, copy fsc.exe in the CIC_FSC directory to the tools directory

  1. Place your XXXXXXX.fsc into your tools directory (same location as the Base64.exe)
  2. Open a command prompt (DOS Screen) and go to the tools directory
  3. Type “Base64 XXXXXXX.FSC XXXXXXX_0001B001.FSC” and press enter
  4. Open BMWFSCNBTGenerator.
Map

exe

  1. Click “Browse” and select the XXXXXXX_0001B001.FSC file you generated in step 3, it

should be in your tools directory.

  1. Choose your map product from the list (Road Map EUROPE PREMIUM 20141)
  2. Click “Generate”

Preparing the USB stick:

Takes about 45 mins to upload the Maps to your car; make sure you enter the code

in CAPITALS, it has been said that you should have the car on/running during this period. But

for me just pressing the Start button once was enough. Once the update is done, you will get

a success message, wait a few minutes then turn the car on/off and then the version number

will reflect the new map.

NBT

USB stick needs to be FAT32 (32GB is enough), when you extract the map data to the stick

1 (directory)

2 (directory)

3 (directory)

4 (directory)

config.nfm

NBT_ECE_101141.3.111.pkg

NBT_ECE_101141.3.111.pkg.sig

CIC

For the PREMIUM (CIC) maps you will have 3 directories:

USB1 (directory)

USB2 (directory)

Bmw Fsc Code Generator Cic Nbt

USB3 (directory)

Copy the entire contents of USB1 to the root of the USB stick, should only be the following:

config.nfm

pkgdb (directory)

Once uploaded to the car, the car will ask for USB2. Delete the both the config.fm and pkgdb

Bmw

from the root and repeat the above with USB2….and then again with USB3.

Notes:

What happens when NEXT/Premium 20152comes out?

You just need to edit the Lookup.xml file with the new map details, just look at the previous entries, its follows a sequence.

Maybe you want visit: 3 steps to generate BMW CIC& NBT FSC Code

Backup your FSC file!!!

Save your XXXXXXX_000DE001.FSC file, you can now just refer to this file and generate as and when the new maps come along. If you lose this file you will need to do the extraction steps again.

  1. All above is quoted from http://f30.bimmerpost.com/forums/, thanks for sharing.
