In computer networking, Cisco ASA 5500 Series Adaptive Security Appliances, or simply Cisco ASA, is Cisco's line of network security devices introduced in May 2005,[1] that succeeded three existing lines of popular Cisco products:

  • Cisco PIX, which provided firewall and network address translation (NAT) functions ended sale on 28 July 2008.[2]
  • Cisco IPS 4200 Series, which worked as intrusion prevention systems (IPS).
  • Cisco VPN 3000 Series Concentrators, which provided virtual private networking (VPN).

Quite the same Wikipedia. Pix To Asa Migration Tool 8.4 Upgrade Your Old. You ca upgrade your old ASA first to 8.4, test it in the lab, compare the configuration and when it is correct, copy the startup config to the new ASA and use it as your running config. You can refer to these docs for it: Migration Guide: You can use this doc as well.

The Cisco ASA is a unified threat management device, combining several network security functions in one box.[3]

Reception and criticism[edit]

Cisco ASA has become one of the most widely used firewall/VPN solutions for small to medium businesses.[4] Early reviews indicated the Cisco GUI tools for managing the device were lacking.[5]

A security flaw was identified when users customized the Clientless SSLVPN option of their ASA's but was rectified in 2015.[6]Another flaw in a WebVPN feature was fixed in 2018.[7]

In 2017 The Shadow Brokers revealed the existence of two privilege escalation exploits against the ASA called EPICBANANA[8] and EXTRABACON.[9][10] A code insertion implant called BANANAGLEE, was made persistent by JETPLOW.[11]

Features[edit]

The 5506W-X has a WiFi point included.

Architecture[edit]

The ASA software is based on Linux. It runs a single Executable and Linkable Format program called lina. This schedules processes internally rather than using the Linux facilities.[12] In the boot sequence a boot loader called ROMMON (ROM monitor) starts, loads a Linux kernel, which then loads the lina_monitor, which then loads lina. The ROMMON also has a command line that can be used to load or select other software images and configurations. The names of firmware files includes a version indicator, -smp means it is for a symmetrical multiprocessor (and 64 bit architecture), and different parts also indicate if 3DES or AES is supported or not.[12]

The ASA software has a similar interface to the Cisco IOS software on routers. There is a command line interface (CLI) that can be used to query operate or configure the device. In config mode the configuration statements are entered. The configuration is initially in memory as a running-config but would normally be saved to flash memory.[12]

software versions[12]
major release7.07.17.28.08.18.28.38.48.58.68.79.09.19.29.39.49.59.69.79.89.9
released[13]31 May 20056 Feb 200631 May 200618 Jun 20071 Mar 20086 May 20098 Mar 201031 Jan 20118 Jul 201128 Feb 201216 Oct 201229 Oct 20123 Dec 201224 Apr 201424 Jul 201430 Mar 201512 Aug 201521 Mar 20164 Apr 201715 May 20174 Dec 2017
end of life××××××××××××××
for 5505-5550YYYYYYYYY
for 5512-5585-XYYYYYYYYYYYY

Options[edit]

The 5512-X, 5515-X, 5525-X, 5545-X and 5555-X can have an extra interface card added.[14]

The 5585-X has options for SSP. SSP stands for security services processor.[15] These range in processing power by a factor of 10, from SSP-10 SSP-20, SSP-40 and SSP-60. The ASA 5585-X has a slot for an I/O module. This slot can be subdivided into two half width modules.[16]

On the low end models, some features are limited, and uncrippling happens with installation of a Security Plus License. This enables more VLANs, or VPN peers, and also high availability.[14] Cisco AnyConnect is an extra licensable feature which operates IPSec or SSL tunnels to clients on PCs, iPhones or iPads.[17]

Models[edit]

The 5505 introduced in 2010 was a desktop unit designed for small enterprises or branch offices. It included features to reduce the need for other equipment, such as an inbuilt switch, and power over Ethernet ports.[18]The 5585-X is a higher powered unit for datacenters introduced in 2010.[19] It runs in 32 bit mode on an Intel architecture Atom chip.[12]

Pix To Asa Migration Tool 8.4 Download

Model5505[20]55105520[20]5540[20]5550[20]5580-20[20]5580-40[20]5585-X SSP10[20]5585-X SSP20[20]5585-X SSP40[20]5585-X SSP60[20]
Cleartextthroughput, Mbit/s1503004506501,2005,00010,0003,0007,00012,00020,000
AES/Triple DES throughput, Mbit/s1001702253254251,0001,0001,0002,0003,0005,000
Max simultaneous connections10,000 (25,000 with Sec Plus License)50,000 (130,000 with Sec Plus License)280,000400,000650,0001,000,0002,000,0001,000,0002,000,0004,000,00010,000,000
Max site-to-site and remote access VPN sessions10 (25 with Sec Plus License)2507505,0005,00010,00010,0005,00010,00010,00010,000
Max number of SSL VPN user sessions252507502,5005,00010,00010,0005,00010,00010,00010,000
Model550555105520554055505580-205580-405585-X SSP105585-X SSP205585-X SSP405585-X SSP60

Cisco determined that most of the low end devices had too little capacity to include the features needed, such as anti-virus, or sandboxing, and so introduced a new line called next generation firewall. These run in 64 bit mode.[12]

Pix

Pix To Asa Migration Tool 8.4 Pro

Models as of 2018.[14]

Model5506-X5506W-X5506H-X5508-X5512-X5515-X5516-X5525-X5545-X5555-X5585-X
Throughput Gb/s0.250.250.250.450.30.50.851.11.51.754-40
GB ports88486688886-8
Ten GB ports00000000002-4
Form factordesktopdesktopdesktop1 RU1 RU1 RU1 RU1RU1RU1RU2RU

Pix To Asa Migration Tool Download
